Architectural Tile 607

Architectural Tile 607 is a fiberglass ceiling panel with an undulating surface for design-led interiors. The UET product handbook lists square-edge, tegular-edge and concealed-grid options, with panel configurations for modular ceiling layouts. Confirm the selected size, thickness, edge and acoustic documentation before specifying or ordering.

Architectural Tile 607 Specifications

*Edge detail*	*Thickness*	*Panel sizes listed in handbook*	*NRC*	*Light reflectance*
Square edge	15 mm	600 × 600 mm; 600 × 1200 mm	0.85	0.88
Square edge	20 mm	600 × 600 mm; 600 × 1200 mm; 1200 × 1200 mm	0.90	0.88
Tegular edge	15 mm	600 × 600 mm; 600 × 1200 mm	0.85	0.88
Tegular edge	20 mm	600 × 600 mm; 600 × 1200 mm	0.90	0.88
Concealed-grid edge	20 mm	600 × 600 mm; 600 × 1200 mm; 1200 × 1200 mm	0.95	0.88

The 1200 × 1200 × 20 mm size appears in the handbook’s performance table but not in its packing list. Confirm current availability before specifying or ordering. Acoustic figures are handbook-listed values; request current test documentation for the selected size, thickness, edge and installation.

*Specification*	*Textured Ceiling Tile 606-2*
Product code	607
Panel material	Dry high-density glass fiber
Surface	Undulating surface
Surface coating	Natural stone powder
Edge options	Square edge; tegular edge
Fire classification	A2
Moisture resistance	RH99

Values shown are from the supplied UET product handbook. Acoustic performance varies with panel configuration. Confirm available sizes, the relevant test method and current documents for the selected edge, thickness and installation before specifying or ordering.

Project Applications to Consider

The UET product handbook recommends Architectural Tile 607 for retail stores and malls. Match the selected ceiling configuration to the project’s visual design, acoustic requirements and installation conditions.

Retail Stores

Use the undulating ceiling surface as part of the store’s interior design. Confirm the selected size, edge detail and installation layout for the project.

Malls

Coordinate the panel configuration with the mall’s shared-space design, acoustic brief and maintenance requirements.

Installation & Compatibility

Before specifying Architectural Tile 607, confirm the available panel size, thickness and edge detail for the selected configuration. Check suspension-grid compatibility, perimeter details, service access and installation conditions against the project drawings and current technical documents. The concealed-grid option should not be assumed to use the same installation detail as square-edge or tegular-edge panels.

Product Documents & Inquiry

For an Architectural Tile 607 inquiry, share the required size, thickness, edge detail, estimated quantity, project location and any ceiling drawings or specifications. Contact UET Ceilings to confirm current availability, samples, technical documents and ordering details.
